Pillar jib crane with girder boom and tie rods and movable plinth

Pillar jib crane with girder boom and tie rods with capacity up to 500 kg

The jib crane on a movable plinth allows operators to shift the crane, using suitable lifting equipment, to more than one location in the factory or construction site, without the constraint of a permanent anchorage to the ground. Extremely versatile, this type of jib crane combines ease of movement and positioning wherever needed in the working environment with the practicality and economy of use that are the added value of the entire category.

The pillar jib crane with girder boom with tie rods and movable plinth is a solution that, thanks to the use of tie rods, is particularly suitable for higher capacities and extensions, compared to the version with a cantilever girder. Easy to install, it is used for handling light loads in a great many industrial applications, from small workshops to large assembly lines, food production plants or wine cellars.

500kg
Maximum capacity
6m
Maximum extension
270°
Rotation
Pillar jib crane with girder boom and tie rods and movable plinth - Image 1

Advantages of the pillar jib crane with girder boom with tie rods and movable plinth

Ease of movement
Operational versatility
Easy to use
Precise control
Increased productivity and safety

Product and configurations

Portable Gantry crane configuration 1

Standard features

Capacity
125 kg - 500 kg
Extension
Up to 6 m depending on capacity
Extension profile
Profile with I beams with tie rods
Rotation
270° with stop adjustable on site depending on architectural dimensions
Plinth
Movable round plinth in concrete or steel formwork with concrete filling
Pillar
Circular-section tubular steel. At one end it has a perforated base plate for anchoring to the base using chemical anchors or anchor rods, and at the other end two plates, a head plate and an intermediate plate, for supporting the boom.
Hoist
Chain or rope electric hoist for lifting the load, with one or two lifting speeds, with electric or push trolley.
Braking device
This consists of a screw-adjustable clutch for the adjustment of the boom rotation effort and for ensuring its positioning stability.

Optional features

Custom paintwork
The paint colour can be customised to meet specific needs, design or branding requirements.
